| Sampling Section |
Max. Polyphony |
64 |
| Signal Processing |
16-bit linear, 8-bit linear
Stereo sampling supported.
A/D 18-bit
D/A 18-bit |
| Sampling Frequencies |
Analog input: 44.1, 22.05, or 11.025 kHz
(Results can be monitored at any frequency prior to recording.)
Digital or optical input: 48.0 or 32.0 kHz |
| Sampling Wave Memory |
4MB RAM (standard) |
Sampling Time
(with standard 4MB RAM) |
At 44.1 kHz, stereo, 16-bit: 22.3 sec.
At 22.05 kHz, mono, 16-bit: 89.3 sec.
At 11.025 kHz, mono, 8-bit: 357.2 sec. |
| Audio Sequencer |
Tempo (BPM)
Synchronization
Tracks
Songs |
40.0 - 299.9
Internal, MIDI sync, MTC slave
42 tracks
Up to 20 songs |
| Effector |
Effector types
Multi-Effector |
43
Three effects can be used simultaneously.
Can be applied to the source from the analog input. |
| User Interface |
Display |
Custom 4-color fluorescent (FL) display
16-alphanumeric display area; segment display area; custom display area |
Pads
Knobs
Ribbon Controller |
12 pads (8 pads are touch [velocity] sensitive)
12 rotary-encoder knobs (non-click type)
1 |
| Data Storage |
Internal Drive |
Floppy Disk Drive (3.5-inch 2DD/2HD) |
| Connection Terminals |
Line Out
Line/Mic In
Headset
MIDI
AC Inlet |
L/MONO and R (phone jacks)
L and R (phone jacks)
Stereo phone jack (High output level)
MIDI IN/OUT |
| Power Ratings |
US
Europe & UK |
120V, 30W
220V to 240V, 30W |
| Dimensions |
14.3" (W) x 12.2" (D) x 4.5" (H) (363 x 310 x 115 mm) |
| Weight |
13.2 lb. (6.0kg) |
